2-292132-6 TE Connectivity 2-292132-6 is a 6-position, single-row, through-hole header with 2.00mm pitch. It features a shrouded design with detent lock for board-to-cable/wire applications.
Mfr Part #:

2-292132-6

Available from 1 distributors
Mfr Name: TE Connectivity
TE Connectivity
TE Connectivity 2-292132-6 is a 6-position, single-row, through-hole header with 2.00mm pitch. It features a shrouded design with detent lock for board-to-cable/wire applications.
✓ Total Stock: 7,000 pcs
$ Price Range: $0.66

2-292132-6 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Tokyo Device ✓
Non-Authorised Inventory information
7,000 pcs
On Request
7000 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

2-292132-6 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Contact Length
Contact Material
Contact Shape
Contact Type
Current Rating (Amps)
Fastening Type
Insulation Color
Insulation Height
Insulation Material
Lead Style
Material Flammability Rating
Mounting Type
Number of Positions
Number of Positions Loaded
Number of Rows
Overall Contact Length
Pitch
Shrouding
Style
Tape & Reel
Termination
Termination Style
Voltage Rating
View Similar Products (0)

2-292132-6 Description

Short technical summary and product information.

The TE Connectivity 2-292132-6 is a 6-position, single-row header designed for board-to-cable/wire connections. It features a through-hole mounting style with kinked pin solder termination for reliable PCB attachment. The connector is shrouded with four walls and includes a detent lock for secure mating.



Key specifications include a 2.00mm pitch, 125VAC voltage rating, and a current rating that varies by wire gauge. The contacts are made of brass with a tin finish, and the insulation is blue polyamide (PA66/Nylon 6/6) with a UL94 V-0 flammability rating. The overall contact length is 9.09mm, with a contact length of 4.20mm and an insulation height of 6.80mm.



This header is suitable for applications requiring a compact, reliable interconnect solution. The shrouded design provides protection and alignment, while the detent lock ensures retention. The single-row configuration and 2.00mm pitch allow for space-efficient layouts on PCBs.

2-292132-6 Quick Information

Product Type: Header, Male Pins
Series: CT
Canonical Name: TE Connectivity 2-292132-6 Header, Male Pins, 6 Position, 2.00mm Pitch, Through Hole
Subcategory: Male Pins

2-292132-6 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

2-292132-6 Estimated Pricing

Qty Low High
16,000+ $0.66 $0.66

Estimated market price range - modelled values for guidance only, not live distributor offers.

2-292132-6 Features

  • 6-position single-row through-hole header.
  • 2.00mm pitch for compact designs.
  • Shrouded with detent lock for secure mating.
  • Rated for 125VAC operation.
  • UL94 V-0 flammability rated insulation.

2-292132-6 Applications

  • Ideal for board-to-cable/wire connections.
  • Used in industrial control systems.
  • Suitable for consumer electronics wiring.
  • Applicable in automotive interior modules.

2-292132-6 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the number of positions?

6 positions.

What is the pitch?

2.00mm.

What is the voltage rating?

125VAC.

What is the mounting type?

Through hole.

What is the current rating?

Varies by wire gauge.

What is the insulation material?

Polyamide (PA66), Nylon 6/6.

What is the contact finish?

Tin.
