2-284513-3 TE Connectivity 2-284513-3 is a 23-position, 3.81mm pitch shrouded header with right angle orientation. It features through hole mounting, solder termination, and tin contact plating.
Mfr Part #:

2-284513-3

Available from 1 distributors
Mfr Name: TE Connectivity
TE Connectivity
TE Connectivity 2-284513-3 is a 23-position, 3.81mm pitch shrouded header with right angle orientation. It features through hole mounting, solder termination, and tin contact plating.
✓ Total Stock: 50 pcs
$ Price Range: $6.24

2-284513-3 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Bristol Electronics ✓
Non-Authorised Inventory information
50 pcs
On Request
50 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

2-284513-3 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Color
Contact Mating Finish
Current
Header Orientation
Lead Spacing
Mounting Type
Number of Levels
Number of Positions
Operating Temperature
Pitch
Positions Per Level
Termination Style
Type
Voltage
View Similar Products (0)

2-284513-3 Description

Short technical summary and product information.

The TE Connectivity 2-284513-3 is a 23-position, single-level terminal block header with a pitch of 3.81mm (0.150 inches). It is a shrouded (4-sided) header designed for reliable wire-to-board connections. The header has a right-angle orientation and is mounted via through-hole soldering, making it suitable for permanent PCB attachment. Contact surfaces are finished with tin, providing good solderability and corrosion resistance. The housing is colored green, a common identifier for terminal block headers. Electrically, the component is rated for 11A current and 300V voltage, with an operating temperature range of -40°C to 110°C. This component is RoHS3 compliant and unaffected by REACH, with an MSL of 1 (unlimited). It is used in various industrial and commercial applications requiring secure and organized wiring.

2-284513-3 Quick Information

Product Type: Terminal Block Header
Canonical Name: TERM BLOCK HDR 23POS 3.81MM
Subcategory: Terminal Block Headers

2-284513-3 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

2-284513-3 Estimated Pricing

Qty Low High
2,000+ $6.24 $6.24

Estimated market price range - modelled values for guidance only, not live distributor offers.

2-284513-3 Features

  • 23 positions with 3.81mm pitch spacing.
  • Right angle orientation for space-saving layouts.
  • Through hole mounting with solder termination.
  • Rated for 11A current and 300V voltage.
  • Tin contact finish for reliable connections.

2-284513-3 Applications

  • Industrial control and automation systems.
  • Building management and HVAC equipment.
  • Power supply and distribution panels.
  • Ideal for PCB-to-wire connections in tight spaces.

2-284513-3 FAQs

7 frequently asked questions generated from this part’s specifications.
How many positions does the 2-284513-3 have?

23 positions.

What is the pitch of the 2-284513-3?

3.81mm (0.150 inches).

What is the current rating of the 2-284513-3?

11A.

What is the voltage rating of the 2-284513-3?

300V.

What mounting type does the 2-284513-3 use?

Through hole.

What is the operating temperature range?

-40°C to 110°C.

What is the contact finish?

Tin.
