| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
100 pcs
|
100 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Contact Mating Finish | |
| Current | |
| Features | |
| Header Orientation | |
| Lead Spacing | |
| Mounting Type | |
| Number of Levels | |
| Number of Positions | |
| Operating Temperature | |
| Pitch | |
| Positions Per Level | |
| Tape & Reel | |
| Termination Style | |
| Type | |
| Voltage |
The TE Connectivity 2-1546175-2 is a terminal block header designed for wire-to-board connections. It has 22 positions arranged in a single level with a vertical orientation.
Key specifications include a 5.00mm pitch, through hole mounting, and solder termination. The header is shrouded on two sides for polarization and features a side stacking capability for modular expansion. The housing is black, and contacts have a tin mating finish.
Electrical ratings are 300V and 15A. The operating temperature range is -40°C to 110°C. The component is RoHS3 compliant with MSL 1 (unlimited) and REACH unaffected. It is suitable for industrial control, power distribution, and automation equipment.
| Qty | Low | High |
|---|---|---|
| 300+ | $9.91 | $9.91 |
| 600+ | $9.48 | $9.48 |
| 1,200+ | $9.15 | $9.15 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
22 positions.
5.00mm (0.197").
15A.
300V.
Through hole.
-40°C to 110°C.
Yes, RoHS3 compliant.
