The 1N4153-1JANTX is a switching diode manufactured by Microsemi. It features a peak reverse repetitive voltage rating of 75V and a peak average forward current of 0.15A. The diode exhibits a peak non-repetitive surge current of 2A and a typical reverse current of 0.05 µA at 50V.
With a typical forward voltage of 1V and a reverse recovery time of 4ns, this component is designed for switching applications. It operates within a temperature range of -65°C to 175°C.
The diode is packaged in a DO-35 case and is designed for through-hole mounting. Its specifications make it suitable for various electronic circuits requiring fast switching capabilities.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
75V.
0.15A.
4ns.
-65°C to 175°C.
DO-35.
Through Hole.
1V typical.
