| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating (Amps) | |
| Illumination | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| Storage Temperature | |
| Voltage Rating |
The Altech Corporation 1G5UM is a manual motor controller from the V-EA-Series, G-Trip line. This 1-pole circuit breaker features a thermal magnetic trip mechanism and is rated for 5A at 277VAC.
Designed for reliable circuit protection, it offers a short circuit withstand rating of 10kA. The breaker is suitable for DIN rail mounting and has a terminal torque specification of 20 lb.in. Its operating temperature range is -25°C to 55°C.
Key specifications include a terminal protection degree of IP20 and terminal size acceptability for top mounting of 18-3 AWG and bottom mounting of 18-2 AWG, with reversible line/load connections. The standard pack quantity is 12 units.
The current rating is 5A.
The voltage rating is 277VAC.
It has 1 pole.
It is a Thermal Magnetic breaker.
It is designed for DIN Rail mounting.
The operating temperature range is -25°C to 55°C.
The standard pack quantity is 12.
