The Altech Corporation 1G15UM is a manual motor controller and circuit breaker from the V-EA-Series. This single-pole unit features a thermal magnetic trip mechanism and is rated for 15A at 277V AC.
Designed for reliable circuit protection, it offers a short circuit withstand rating of 10kA for 0.3-10A (RC) and 5kA for 13-60A (RC), with an interrupting capacity of 10kA (VDE). The breaker operates within a temperature range of -25°C to 55°C and is calibrated at 40°C.
Mounting is facilitated via a standard DIN rail, and the terminals accept wire sizes from 18-3 AWG on the top and 18-2 AWG on the bottom, with a recommended torque of 20 lb.in. The unit has an IP20 protection degree.
Compliance includes UL508 listing and CSA approval. It is RoHS3 compliant, has an MSL of 1, and is REACH unaffected.
The current rating is 15A.
The voltage rating is 277V.
It has 1 pole.
It is a Thermal Magnetic breaker.
It is designed for DIN Rail mounting.
The operating temperature range is -25°C to 55°C.
The terminals accept 18-3 AWG on the top and 18-2 AWG on the bottom.
