1EDN7550UXTSA1 The Infineon Technologies 1EDN7550UXTSA1 is a single-channel gate driver IC designed for high-side and low-side applications. It offers robust performance with a wide operating voltage range and high output current capabilities.
Mfr Part #:

1EDN7550UXTSA1

Available from 1 distributors
Mfr Name: Infineon Technologies
Infineon Technologies
The Infineon Technologies 1EDN7550UXTSA1 is a single-channel gate driver IC designed for high-side and low-side applications. It offers robust performance with a wide operating voltage range and high output current capabilities.
✓ Total Stock: 9,000 pcs
$ Price Range: $0.91

1EDN7550UXTSA1 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Risen Electronics ✓
Non-Authorised Inventory information
9,000 pcs
On Request
9000 pcs On Request 1 On Request On Request On Request On Request 2026-02-16 21:33:16
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

1EDN7550UXTSA1 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Channel Type
Current
Driven Configuration
Gate Type
Input Type
Mounting Type
Number of Drivers
Operating Temperature
Propagation Delay
Rise
Supplier Device Package
Voltage
View Similar Products (0)

1EDN7550UXTSA1 Description

Short technical summary and product information.

The Infineon Technologies EiceDRIVER™ 1EDNx550 series, including the 1EDN7550UXTSA1, provides single-channel high-side and low-side gate driving capabilities. These ICs feature a fully differential input circuitry for excellent common-mode robustness (CMR), preventing false triggering. The 1EDN7550UXTSA1 is housed in a compact PG-TSNP-6-13 (6-XFDFN) package, suitable for surface mount applications.



Key electrical specifications include an operating voltage range of 4.5V to 20V, with separate low-impedance source (4A) and sink (8A) outputs. It boasts a propagation delay of 45 ns and supports N-Channel and P-Channel MOSFETs. The device operates across a wide temperature range from -40°C to 150°C.



Applications for this gate driver include server, telecom, and industrial SMPS, DC-DC converters, and motor control systems. It is designed to drive SJ and SiC MOSFETs, and GaN HEMTs, making it versatile for various power electronics designs.

1EDN7550UXTSA1 Quick Information

Product Type: Gate Driver
Series: TDI
Canonical Name: 1EDN7550U Single-Channel High-Side and Low-Side Gate Driver
Subcategory: Single-Channel Gate Driver

1EDN7550UXTSA1 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

1EDN7550UXTSA1 Estimated Pricing

Qty Low High
1+ $0.91 $0.91

Estimated market price range - modelled values for guidance only, not live distributor offers.

1EDN7550UXTSA1 Features

  • Single-channel high-side/low-side gate driver.
  • High common-mode rejection ratio (CMR).
  • 4A source and 8A sink output current.
  • 4.5V to 20V operating voltage range.
  • Compact TSNP-6 surface mount package.

1EDN7550UXTSA1 Applications

  • Ideal for industrial SMPS designs.
  • Used in DC-DC converters and bricks.
  • Suitable for motor control applications.
  • Drives SJ, SiC MOSFETs, and GaN HEMTs.

1EDN7550UXTSA1 FAQs

5 frequently asked questions generated from this part’s specifications.
What is the operating voltage range for the 1EDN7550UXTSA1?

The operating voltage range is 4.5 V to 20 V.

What package type is the 1EDN7550UXTSA1 supplied in?

The 1EDN7550UXTSA1 is supplied in a PG-TSNP-6-13 (6-XFDFN) package.

What is the operating temperature range for this gate driver?

The operating temperature range is -40°C to 150°C.

What are the output current capabilities of the 1EDN7550UXTSA1?

It provides separate low-impedance source (4 A) and sink (8 A) outputs.

What is the propagation delay of the 1EDN7550UXTSA1?

The propagation delay is 45 ns.
