Mfr Part #:

1ED020I12-B2

Mfr Name: Infineon

The Infineon 1ED020I12-B2 is a single channel isolated gate driver IC. It offers a typical output current of 2A and features DESAT detection and Miller Clamp.

✓ Total Stock: 6,615 pcs

$ Price Range: $0.99

1ED020I12-B2 Available from 3 distributors

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Xingangxin ✓ Non-Authorised Inventory information	6,413 pcs On Request	6413 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request
Optech Co.,Limited ✓ Non-Authorised Inventory information	199 pcs On Request	199 pcs	On Request	1	On Request	On Request	14+	On Request	On Request
ACK ELEKTRONIK ✓ Non-Authorised Inventory information	3 pcs On Request	3 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request

1ED020I12-B2 Specifications Quick View

Most important parameters for selection – full specs in datasheet.

SELECT ALL

Category	New Products
Manufacturer Name	Infineon
Mounting Type	Surface Mount
Output Current	2 A
Propagation Delay	195 ns

View Similar Products (0)

1ED020I12-B2 Description

Short technical summary and product information.

The Infineon 1ED020I12-B2 is a single channel, coreless transformer isolated gate driver IC designed for 600 V/1200 V IGBTs and SiC MOSFETs. It provides a typical rail-to-rail output current of 2 A.

Key integrated protection features include VCEsat-detection (DESAT), short circuit clamping, active shut-down, and an active Miller clamp. The device has a maximum propagation delay of 195 ns and a common mode transient immunity (CMTI) of 100 kV/µs. It operates with an output undervoltage lockout (UVLO) of 12/11 V and has an absolute maximum output supply voltage of 28 V.

This gate driver IC is certified according to UL 1577 with an isolation voltage of 3750 V (rms) for 1 minute, offering basic insulation. It is suitable for operation at high ambient temperatures.

The 1ED020I12-B2 is housed in a PG-DSO-16-15 package and is qualified for various applications including AC and brushless DC motor drives, high voltage DC/DC converters, UPS systems, solar inverters, and EV charging.

1ED020I12-B2 Quick Information

Product Type: Gate Driver IC

Canonical Name: Infineon 1ED020I12-B2 Single Channel Isolated Gate Driver IC

Subcategory: Isolated Gate Driver

1ED020I12-B2 Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

1ED020I12-B2 Estimated Pricing

Qty	Low	High
1+	$0.99	$0.99

Estimated market price range - modelled values for guidance only, not live distributor offers.

1ED020I12-B2 Features

Single channel isolated gate driver IC.
2 A typical rail-to-rail output current.
Integrated DESAT and Miller Clamp.
100 kV/µs common mode transient immunity.
PG-DSO-16-15 package for surface mounting.

1ED020I12-B2 Applications

Suitable for AC and brushless DC motor drives.
Used in high voltage DC/DC converters.
Applicable for UPS and solar inverters.
Designed for EV charging systems.
Supports commercial and industrial power supplies.
