| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Ambient Temperature | |
| Approval Agency | |
| Breaker Type | |
| Country of Origin | |
| Current Rating (Amps) | |
| Failure Rate | |
| Illumination | |
| Mounting Type | |
| Number of Poles | |
| Rated Current | |
| Rated Voltage | |
| Storage Temperature | |
| Voltage Rating |
The Altech Corporation 1D50DL is a single-pole miniature circuit breaker designed for reliable overcurrent protection. It features a thermal magnetic trip mechanism, providing robust performance in various applications.
With a rated current of 50A and a voltage rating of 125V DC, this circuit breaker is suitable for DC power distribution and control circuits. It is designed for DIN rail mounting, ensuring easy integration into control panels and electrical enclosures.
The 1D50DL offers a degree of protection of IP20 and has an electrical life of 6,000 switching cycles and a mechanical life of 10,000 switching cycles. It operates within an ambient temperature range of -25C to +70C.
This circuit breaker is manufactured in Germany (DE) and carries cULus and UL489 approvals, indicating compliance with relevant safety standards.
The Altech Corporation 1D50DL circuit breaker has a rated current of 50A.
The Altech Corporation 1D50DL circuit breaker is rated for 125V DC.
The Altech Corporation 1D50DL circuit breaker has one pole.
The Altech Corporation 1D50DL uses a thermal magnetic breaker mechanism.
The operating temperature range for the 1D50DL circuit breaker is -25C to +70C.
The Altech 1D50DL circuit breaker has a degree of protection of IP20.
The electrical life of the Altech Corporation 1D50DL circuit breaker is 6,000 switching cycles ON/OFF.
