| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
400 pcs
|
400 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Current | |
| Hole Diameter | |
| Lead Spacing | |
| Length | |
| Mating Orientation | |
| Mounting Type | |
| Number of Levels | |
| Pitch | |
| Positions Per Level | |
| Termination Style | |
| Voltage | |
| Wire Gauge | |
| Wire Termination |
The Phoenix Contact 1991118 (SPT 2,5/ 4-V-5,0) is a 4-position PCB terminal block with a 5mm pitch. It features a screwless spring cage connection (tension clamp) for tool-less wiring of solid or stranded conductors up to 2.5 mm². The terminal block is rated for a nominal current of 24 A and a nominal voltage of 400 V, with a rated surge voltage of 4 kV. It is designed for through hole mounting with a vertical mating orientation (90° conductor connection direction).
The insulating material is polyamide (PA) with a flammability class of UL94 V0. The housing is green. The terminal block has two solder pins for enhanced mechanical stability on the PCB. The wire range is 12-24 AWG with a stripping length of 10 mm. Pin dimensions are 0.8 x 0.8 mm, and the recommended PCB hole diameter is 1.1 mm.
This terminal block is part of the SPT 2,5/..-V series and is suitable for industrial control, automation, and power distribution applications. It supports push-in direct plug-in technology for solid conductors and stranded conductors with ferrules. For stranded conductors without ferrules, a standard screwdriver is used to open the terminal point.
4 positions.
5.00 mm.
Nominal current is 24 A (datasheet).
Nominal voltage is 400 V (datasheet).
Through hole.
Screwless spring cage, tension clamp.
