The Kester 197 Soldering Flux is a mildly activated rosin liquid flux. It is formulated as a homogeneous solution of high-quality purified Grade WW rosin within a specially blended alcohol vehicle. A very small amount of an extremely effective activating agent is incorporated into the mixture.
Classified as Type ROL1 flux under IPC ANSI/J-STD-004 and formerly QPL approved as Type RMA under MIL-F-14256, the 197 flux offers fluxing ability comparable to highly activated rosin fluxes. However, its residue is considerably less conductive due to a minimum of ionic activating agent, as indicated by its very high water extract resistivity. The rosin residue is non-corrosive, non-conductive, and resistant to moisture and fungus. The dry residue provides insulation against atmospheric corrosion.
This liquid flux is classified as a Category 2 Flammable Liquid and a Category 2 Eye Irritant. It may also cause an allergic skin reaction and drowsiness or dizziness. It is intended for use outdoors or in well-ventilated areas, with precautions taken to prevent static discharges and ignition sources.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The Kester 197 is a mildly activated rosin liquid flux, classified as Type ROL1 under IPC ANSI/J-STD-004.
It is a homogeneous solution of high quality purified Grade WW rosin in a specially blended alcohol vehicle with a small amount of activating agent.
The rosin residue is non-corrosive, non-conductive, moisture and fungus resistant, and provides insulation against atmospheric corrosion.
It is a highly flammable liquid and vapor, may cause an allergic skin reaction, causes serious eye irritation, and may cause drowsiness or dizziness.
The RoHS Status is listed as RoHS3 Compliant.
The Moisture Sensitivity Level (MSL) is 1 Unlimited.
