1872A Belden 1872A is a Category 6+ premise horizontal cable with 4 unshielded twisted pairs, 23 AWG solid bare copper conductors, and a bonded-pair design for improved performance. It supports frequencies up to 350 MHz and is rated for 300V CMR applications.
Mfr Part #:

1872A

Available from 1 distributors
Mfr Name: Belden Inc.
Belden Inc.
Belden 1872A is a Category 6+ premise horizontal cable with 4 unshielded twisted pairs, 23 AWG solid bare copper conductors, and a bonded-pair design for improved performance. It supports frequencies up to 350 MHz and is rated for 300V CMR applications.
✓ Total Stock: 222 pcs
$ Price Range: $0.99

1872A Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Braun Electronic Components ✓
Non-Authorised Inventory information
222 pcs
On Request
222 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

1872A Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Conductor Material
Insulation Material
Overall Diameter
SVHC Present
Storage Temperature
View Similar Products (0)

1872A Description

Short technical summary and product information.

The Belden 1872A is a Category 6+ (350 MHz) premise horizontal cable designed for high-speed data transmission. It consists of 4 unshielded twisted pairs (UTP) with 23 AWG solid bare copper conductors insulated with polyolefin. The bonded-pair construction reduces pair-to-pair crosstalk and improves signal integrity. The cable is jacketed with PVC, rated for 300V and 75°C operation, with a nominal overall diameter of 0.365 x 0.165 inches. Electrical performance meets or exceeds Category 6+ requirements up to 350 MHz, with insertion loss of 19.8 dB/100m at 100 MHz, NEXT of 45.3 dB, and ACR of 25.5 dB. The cable has a characteristic impedance of 100 ohms and a velocity of propagation of 70%. It is suitable for Ethernet applications including 10GBASE-T and Power over Ethernet (PoE) in structured cabling systems.

1872A Quick Information

Product Type: Ethernet Cable
Canonical Name: Belden 1872A Category 6+ Premise Horizontal Cable (350MHz)
Subcategory: Category 6+ Ethernet Cable

1872A Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

1872A Estimated Pricing

Qty Low High
1+ $0.99 $0.99

Estimated market price range - modelled values for guidance only, not live distributor offers.

1872A Features

  • Category 6+ performance up to 350 MHz.
  • 4 unshielded twisted pairs with bonded-pair design.
  • 23 AWG solid bare copper conductors.
  • PVC jacket rated for 300V and 75°C.
  • Nominal velocity of propagation 70%.

1872A Applications

  • Ideal for high-speed Ethernet networks up to 10GBASE-T.
  • Suitable for premise horizontal cabling in offices and data centers.
  • Supports Power over Ethernet (PoE) applications.
  • Used in structured cabling systems requiring Category 6+ performance.

1872A FAQs

6 frequently asked questions generated from this part’s specifications.
What is the operating voltage rating of this cable?

300V.

What is the operating temperature range?

75°C.

What is the conductor size?

23 AWG.

How many pairs are in this cable?

4 pairs.

Is this cable bonded-pair?

Yes.

What is the maximum pull tension?

40 lbs.
