| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
47 pcs
|
47 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
4 pcs
|
4 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Accessory Type | |
| For Use With | |
| Mounting Type | |
| Storage Temperature | |
| Tape & Reel | |
| Termination Style |
The Vicor 18372 is an InMate through-hole socket-mount system designed for use with VICOR Micro-Sized DC-DC converters. It consists of a plastic carrier factory-loaded with 5 input and 5 output sockets, which hold the sockets rigidly during assembly and soldering. After soldering, the carrier is removed, leaving the sockets accurately positioned on the PCB.
This socket is compatible with through-hole mounting and solder termination, supporting wave or hand soldering processes. The sockets accommodate PCB thicknesses ranging from 0.055in to 0.1375in and allow for inboard or onboard module mounting. The product is supplied in standard recyclable JEDEC style trays suitable for automated pick-and-place equipment.
RoHS3 compliant and REACH unaffected, the Vicor 18372 is a reliable socket solution for integrating Micro-Sized modules into power supply designs.
Through-hole mounting.
5 input and 5 output sockets.
VICOR Micro-Sized Modules.
Solder.
Tray (JEDEC style).
RoHS3 Compliant (unverified).
