| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
50 pcs
|
50 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Contact Mating Finish | |
| Current | |
| Current Rating | |
| Features | |
| Header Orientation | |
| Lead Spacing | |
| Mounting Type | |
| Number of Levels | |
| Number of Positions | |
| Pitch | |
| Positions Per Level | |
| Termination Style | |
| Type | |
| Voltage | |
| Voltage Rating |
The Phoenix Contact 1830169 is a shrouded (4 side) terminal block header designed for reliable wire-to-board connections in industrial control and automation systems. It features 16 male pin positions arranged in 2 levels with 8 positions per level, spaced at 3.81mm pitch. The right-angle orientation allows for low-profile mating when board space is constrained.
Rated for 300V and 8A, the header uses tin-plated contacts for good conductivity and corrosion resistance. The green housing includes a board guide and mating flange for secure alignment and locking with the corresponding plug. Through-hole solder termination provides a robust mechanical connection to the PCB.
This component is RoHS3 compliant, REACH unaffected, and has an MSL of 1 (unlimited) for moisture sensitivity. Typical applications include industrial controls, building automation, and power distribution panels.
The pitch is 3.81mm.
It has 16 positions arranged in 2 levels with 8 positions per level.
The current rating is 8A.
The voltage rating is 300V.
It uses through-hole mounting with solder termination.
