| Category | |
| Manufacturer Name | |
| Contact Material | |
| Contact Plating | |
| Country of Origin | |
| Current Rating | |
| Failure Rate | |
| Frame Type | |
| Housing Material | |
| Mounting Type | |
| Number of Contacts | |
| Operating Voltage | |
| Orientation | |
| Pitch | |
| Product Type | |
| Termination Style |
The RS PRO 183-1563 is a vertical DIL socket featuring 16 contacts and a 2.54mm pitch. It is designed for through-hole mounting and utilizes turned pin contacts with tin plating.
This socket has a current rating of 3A and an operating voltage of 60V. It operates within a temperature range of -40°C to 105°C. The housing is made of thermoplastic material, and the contact material is brass with beryllium copper alloy.
Key specifications include a closed frame design and solder termination type. The country of origin for this component is China. It is part of the RS PRO series.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.10 | $0.10 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The pitch of this DIL socket is 2.54mm.
This DIL socket has 16 contacts.
The current rating for this socket is 3A.
The maximum operating temperature for this DIL socket is 105°C.
The minimum operating temperature for this DIL socket is -40°C.
This DIL socket uses through-hole mounting.
