| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
10 pcs
|
10 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Actuator Level | |
| Actuator Type | |
| Body Material | |
| Circuit | |
| Contact Finish | |
| Contact Material | |
| Current Rating | |
| Current Rating (Amps) | |
| Electrical Life | |
| Height Above Board | |
| Mechanical Life | |
| Mounting Type | |
| Number of Positions | |
| Operating Temperature | |
| Pitch | |
| Tape & Reel | |
| Termination Style | |
| Voltage Rating | |
| Washable |
This TE Connectivity 1825057-4 is a single-pole, single-throw (SPST) DIP switch designed for through-hole mounting. It offers 5 positions and operates with a current rating of 100mA and a voltage rating of 24VDC.
The switch features a standard slide actuator and a raised actuator level for ease of use. The contact finish is gold, and the contact material is copper alloy, ensuring reliable connections. The pitch between pins is 2.54mm (0.100"), and the height above the board is 0.228" (5.80mm).
With a body material of Polyphenylene Sulfide (PPS), this DIP switch is built for durability. It operates within a temperature range of -30°C to 85°C. The electrical and mechanical life are both rated for 1,000 cycles.
This component is packaged in a tube and is washable. It is RoHS3 compliant and has a Moisture Sensitivity Level (MSL) of 1 Unlimited.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.75 | $0.75 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The voltage rating is 24VDC.
It has 5 positions.
The current rating is 100mA.
The operating temperature range is -30°C to 85°C.
It features a standard slide actuator.
Yes, this part is RoHS3 Compliant.
The MSL is 1 Unlimited.
