| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
48 pcs
|
48 pcs | On Request | 1 | On Request | On Request | N/A | On Request | On Request | |
|
2 pcs
|
2 pcs | On Request | 1 | On Request | On Request | 11+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Backset Spacing | |
| Connector Style | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Features | |
| Flange Feature | |
| Insulator Material | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Shell Material, Finish | |
| Shell Size, Connector Layout | |
| Termination | |
| Termination Style |
The 181-026-113R531 is a 26-position D-Sub high density plug from NorComp's 181 Series. It features a right angle solder termination for space-constrained PCB layouts and a panel mount design with through hole mounting. The connector includes board locks and grounding indents for secure attachment and additional retention. The metal shell provides EMI/RFI shielding, and the plug shell has indents for grounding. Contacts are brass with gold flash plating, ensuring reliable signal transmission. The insulator is PA9T black with UL94 V-0 flammability rating, suitable for high-temperature processing. The shell is steel with nickel plating. With a current rating of 3A and a backset spacing of 0.350" (8.89mm), this connector is designed for signal applications in industrial, communications, and medical equipment where space and shielding are critical.
26 positions.
3A.
Panel mount, through hole, right angle.
Steel, nickel plated.
PA9T black, UL94 V-0.
Yes, it features board lock, grounding indents, and shielding.
