| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2 pcs
|
2 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Mounting Type | |
| Weight |
The Allen Bradley 1794-TB3 is a terminal base unit designed for use with the Flex I/O 1794 series. This component facilitates direct wiring from sensors to the terminal base, reducing space requirements and eliminating the need for terminal strips.
Key specifications include an operating temperature range of 0°C to 55°C. It supports a FLEXBus voltage of 5V DC with a current capacity of 640 mA. The V/COM terminal offers a supply voltage of 125V AC/DC and a continuous current rating of 10 Amps, with an isolation voltage of 125 Volts. The terminal screw torque is specified between 0.56 to 0.79 Nm.
Engineered for DIN rail mounting, the 1794-TB3 utilizes cage-clamp connections for secure and reliable electrical connections. Its design contributes to increased productivity through easy configuration and setup of I/O modules, speeding up engineering and installation processes. The unit's robust construction and specifications make it suitable for various industrial automation applications.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The FLEXBus terminal operates at 5V DC.
The V/COM terminal is rated for 10 Amps continuous.
The operating temperature range is 0°C to 55°C.
It is mounted on a DIN rail.
It uses Cage-Clamp terminals.
The isolation voltage is 125V.
The terminal screw torque is 0.56 to 0.79 Nm.
