| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
4,570 pcs
|
4570 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Fastening Type | |
| Features | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Termination | |
| Termination Style | |
| Voltage Rating |
The TE Connectivity 178328-2 is a 20-position, 2-row rectangular header connector with a 3.81mm pitch and 5.08mm row spacing. It is designed for board-to-board or cable applications and features a shrouded 4-wall housing with a detent lock fastening mechanism and a board lock for secure attachment. The contacts are made of copper alloy with a tin finish (0.38µm thickness) and are rectangular tab type. The insulation is black thermoplastic, polyester, glass filled with a UL94 V-0 flammability rating.
The connector has an insulation height of 21.59mm and a contact length of 3.81mm. It is rated for 250V and operates over a temperature range of -55°C to 105°C. The mounting type is through hole with solder termination. All 20 positions are loaded. The connector is RoHS compliant (unverified) and has an MSL of 1 Unlimited (unverified).
20 positions arranged in 2 rows.
The pitch is 3.81mm (0.150 inches).
250V.
Through hole with solder termination.
-55°C to 105°C.
Tin with a thickness of 0.38µm.
Thermoplastic, polyester, glass filled with UL94 V-0 rating.
