| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
6 pcs
|
6 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Contact Mating Finish | |
| Current | |
| Features | |
| Height | |
| Industrial Grade | |
| Lead Spacing | |
| Length | |
| Mounting Type | |
| Number of Levels | |
| Number of Positions | |
| Pitch | |
| Plug Wire Entry | |
| Positions Per Level | |
| SVHC Present | |
| Termination Style | |
| Type | |
| Voltage | |
| Wire Gauge or Range |
The Phoenix Contact 1778120 is an 8-position terminal block plug from the PC 5/..-STCL1 series. It features a 7.62mm pitch and is designed for free hanging (in-line) mounting with 180° wire entry. The plug uses a screw connection with a rising cage clamp termination style, ensuring reliable wire retention.
Rated for a nominal current of 41A and a rated voltage of 1000V (III/2), this plug supports conductor cross sections from 0.2 to 10 mm² solid and 0.2 to 6 mm² stranded, corresponding to 24-10 AWG. The contact mating finish is tin, and the insulating material is polyamide (PA) with a flammability class of V0 per UL 94.
Mechanical features include an M3 screw thread with a tightening torque of 0.7-0.8 Nm and a stripping length of 10 mm. The plug is green in color and incorporates a latch lock for secure mating. The package quantity is 50 pieces per standard pack.
8 positions.
7.62mm (0.300 inches).
41 A.
Rated voltage (III/2) is 1000 V per datasheet; general specification shows 600 V.
Free hanging (in-line).
Solid: 0.2-10 mm², stranded: 0.2-6 mm², AWG: 24-10.
0.7-0.8 Nm.
