1777206 Phoenix Contact 1777206 is a 15-position, 5.08mm pitch terminal block header with shrouded male pins. It features a vertical orientation, through hole mounting, and a green PBT insulator.
Mfr Part #:

1777206

Available from 2 distributors
Mfr Name: Phoenix Contact
Phoenix Contact
Phoenix Contact 1777206 is a 15-position, 5.08mm pitch terminal block header with shrouded male pins. It features a vertical orientation, through hole mounting, and a green PBT insulator.
✓ Total Stock: 86 pcs

1777206 Available from 2 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Braun Electronic Components ✓
Non-Authorised Inventory information
71 pcs
On Request
71 pcs On Request 1 On Request On Request On Request On Request On Request
Bristol Electronics ✓
Non-Authorised Inventory information
15 pcs
On Request
15 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

1777206 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Color
Contact Mating Finish
Current
Features
Header Orientation
Hole Diameter
Lead Style
Length
Mounting Type
Number of Levels
Number of Positions
Pitch
Positions Per Level
Tape & Reel
Termination Style
Type
Voltage
View Similar Products (0)

1777206 Description

Short technical summary and product information.

The Phoenix Contact 1777206 is a 15-position terminal block header from the MSTBV 2,5/..-GF series. It has a pitch of 5.08 mm and is designed for through hole soldering onto a PCB. The header is shrouded on four sides and includes a mating and mounting flange for secure connection with compatible plugs.



Electrical ratings include a nominal current of 12 A and a rated voltage of 300 V (UL/CUL Use Group B and D) or 320 V (III/2) and 400 V (II/2) per EN-VDE. The insulating material is green PBT with a flammability class of UL 94 V0. Contact mating finish is tin.



This header is suitable for industrial control, automation, and power distribution applications where reliable PCB-to-wire connections are required. The vertical orientation allows for straightforward plug-in direction perpendicular to the PCB.

1777206 Quick Information

Product Type: Terminal Block Header
Series: MSTBV 2,5/..-GF
Canonical Name: Phoenix Contact MSTBV 2,5/15-GF-5,08 Header, 15 Position, 5.08mm Pitch, Through Hole
Subcategory: Terminal Block Headers

1777206 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

1777206 Features

  • 15 positions with 5.08mm pitch.
  • Rated for 12A and 300V.
  • Shrouded header with mating flange.
  • Through hole solder termination.
  • Green PBT insulator, UL 94 V0 rated.

1777206 Applications

  • Used in industrial control systems.
  • Ideal for PCB-to-wire connections.
  • Suitable for power distribution applications.
  • Common in automation equipment.

1777206 FAQs

7 frequently asked questions generated from this part’s specifications.
How many positions does the 1777206 have?

15 positions.

What is the pitch of the 1777206?

5.08 mm.

What is the current rating of the 1777206?

12 A.

What is the voltage rating of the 1777206?

300 V (UL/CUL Use Group B and D) or 320 V (III/2) and 400 V (II/2).

What is the mounting type of the 1777206?

Through hole.

What color is the 1777206 header?

Green.

What is the insulating material of the 1777206?

PBT, flammability class V0.
