| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
30 pcs
|
30 pcs | On Request | 1 | On Request | On Request | 1970-01-01 00:30:52 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Style | |
| Connector Type | |
| Contact Finish | |
| Contact Type | |
| Current Rating (Amps) | |
| Features | |
| Flange Feature | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Shell Material, Finish | |
| Shell Size, Connector Layout | |
| Tape & Reel | |
| Termination |
The TE Connectivity 1761028-2 is a 40-position D-Sub receptacle connector featuring female socket contacts arranged in 2 rows. It uses a right angle through hole mounting style with solder termination, making it suitable for PCB applications where space constraints require a low-profile right angle connection.
This connector is rated for 1 A per contact and uses gold contact finish for reliable signal transmission. The shell is made of steel with nickel plating, providing durability and EMI shielding. It includes board lock features for secure attachment to the PCB and is shielded for enhanced signal integrity.
The connector layout uses a 0.050 inch pitch with 0.100 inch row spacing. The flange includes housing/shell (2-56) threads and latchblocks/rails for mating hardware. The insulator material is rated UL94 V-0 for flammability.
Receptacle, Female Sockets; D-Type.
40 positions arranged in 2 rows.
Through Hole, Right Angle mounting with Solder termination.
1 A per contact.
Gold contact finish.
Steel, Nickel Plated.
UL94 V-0.
