| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2,828 pcs
|
2828 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
306 pcs
|
306 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
150 pcs
|
150 pcs | On Request | 1 | On Request | On Request | N/A | On Request | On Request | |
|
70 pcs
|
70 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
1 pcs
|
1 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Constructional Height | |
| Contact Mating Finish | |
| Country of Origin | |
| Current | |
| Custom Tariff Number | |
| Dimension a | |
| Failure Rate | |
| Flammability Rating | |
| Header Orientation | |
| Height | |
| Hole Diameter | |
| Insulating Material | |
| Lead Spacing | |
| Length | |
| Maximum Load Current | |
| Mounting Type | |
| Nominal Current IN | |
| Number of Levels | |
| Number of Positions | |
| Packing Unit | |
| Pin Dimensions | |
| Pitch | |
| Positions Per Level | |
| Rated Surge Voltage (II/2) | |
| Rated Surge Voltage (III/2) | |
| Rated Surge Voltage (III/3) | |
| Rated Voltage (II/2) | |
| Rated Voltage (III/2) | |
| Rated Voltage (III/3) | |
| Solder Pin Length | |
| Tape & Reel | |
| Termination Style | |
| Type | |
| Voltage | |
| Weight | |
| Width |
The Phoenix Contact 1757268 is a 4-position header from the MSTBA 2,5/..-G series. It features a 5.08mm pitch and a right angle (90°) orientation, making it suitable for PCB mounting where space is constrained. The header is shrouded on four sides for added protection.
Electrical ratings include a nominal current of 12A and a rated voltage of 320V (overvoltage category III/2). The insulating material is PA with a flammability rating of UL 94 V0. The contact mating finish is tin.
The component is through hole mounted with solder termination. Dimensions: length 12mm, width 22.24mm, height 12.1mm, constructional height 8.6mm. The solder pin length is 3.5mm with pin dimensions 1x1mm. Weight per piece is 1.6g. Color is green.
4 positions.
5.08 mm.
12 A nominal current and maximum load current.
Rated voltage is 320 V for overvoltage category III/2, 250 V for III/3, and 400 V for II/2.
Through hole mounting with solder termination.
Green.
UL 94 V0.
