The Allen Bradley 1746-OW4 is a Digital Contact Output Module designed for use with the SLC 500 series PLCs. This module provides 4 Normally Open (N.O.) Relay Contact Outputs, making it suitable for relay contact output applications.
It supports a wide operating voltage range, accepting 5-265 Volts AC or 5-125 Volts DC. The module can handle a current of up to 1.5 amps at 120 VAC and 1.2 amps at 24 VDC per output. The backplane current draw is 45 milliamps.
Key electrical characteristics include a step response time of 60 milliseconds for input and 2.5 milliseconds for output. The module has a weight of 0.45 kg (1.00 lbs).
This component is intended for industrial automation and control systems where reliable digital output switching is required.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The Allen Bradley 1746-OW4 has an operating voltage range of 5-265 Volt AC or 5-125 Volts DC.
The 1746-OW4 module has 4 N.O. Relay Contact Outputs.
The current rating per output at 120 VAC is 1.5 amps.
The output step response time is 2.5 milliseconds.
