| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
9,000 pcs
|
9000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Shrouding | |
| Style | |
| Tape & Reel | |
| Termination | |
| Termination Style | |
| Voltage Rating |
The 1744337-1 from TE Connectivity is a 3-position rectangular connector header with a single row and 3.96mm (0.156") pitch. It features a right-angle through-hole mounting style and solder termination, with brass contacts finished in tin (80µin). The header is shrouded on one wall and includes a friction lock for secure mating.
The housing is molded from natural polyamide (PA66/Nylon 6/6) with a UL94 V-0 flammability rating. It operates over -25°C to 105°C and is rated for 250VAC. Note that this variant has 3 positions but only 2 positions are loaded.
The right-angle orientation allows the wire/cable to exit parallel to the PCB surface, making it suitable for board-to-cable/wire applications where space is limited. The through-hole terminals provide robust mechanical attachment to the PCB. The 3.96mm pitch is commonly used in power and signal interconnects.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.38 | $0.38 |
| 10+ | $0.32 | $0.32 |
| 25+ | $0.29 | $0.29 |
| 100+ | $0.25 | $0.25 |
| 250+ | $0.22 | $0.22 |
| 1,000+ | $0.19 | $0.19 |
| 3,000+ | $0.16 | $0.16 |
| 5,000+ | $0.15 | $0.15 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
It has 3 positions, with 2 positions loaded.
The pitch is 3.96mm (0.156").
250VAC.
Through hole, right angle, with solder termination.
-25°C to 105°C.
Brass with tin finish (80µin).
Yes, it is shrouded on one wall and has a friction lock.
