| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
14,062 pcs
|
14062 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Style | |
| Connector Type | |
| Contact Finish | |
| Contact Type | |
| Current Rating (Amps) | |
| Features | |
| Flange Feature | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Shell Material, Finish | |
| Shell Size, Connector Layout | |
| Termination | |
| Termination Style |
The Molex 1731070059 is a D-Sub Combo plug connector with male pins. It offers 7 positions arranged as 5 signal and 2 coax or power cavities, making it suitable for mixed-signal and power applications. The connector is designed for panel mounting with an unthreaded housing/shell flange and features solder cup termination for secure wire connections.
Key specifications include gold-plated contacts for reliable conductivity and corrosion resistance, a current rating of 5 A per contact, and a steel shell with tin plating for durability and EMI shielding. The insulator is rated UL94 V-0 for flammability, and the connector includes grounding indents for improved ground continuity.
This combo connector allows designers to consolidate signal and power/coax connections in a single D-Sub shell, saving space. Note that the signal and coax or power contacts are not included and must be ordered separately. The connector's shell size is 2 (DA, A) - 7W2, compatible with standard D-Sub panel cutouts.
Typical applications include industrial control systems, data communication equipment, and instrumentation where a combination of signal and higher-current or coaxial connections is required. The panel-mount design with solder cup termination simplifies assembly in fixed installations.
| Qty | Low | High |
|---|---|---|
| 1+ | $5.30 | $5.30 |
| 10+ | $4.84 | $4.84 |
| 20+ | $4.68 | $4.68 |
| 100+ | $4.47 | $4.47 |
| 200+ | $4.13 | $4.13 |
| 500+ | $3.84 | $3.84 |
| 1,000+ | $3.62 | $3.62 |
| 2,000+ | $3.53 | $3.53 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
7 positions, arranged as 5 signal and 2 coax or power.
5 A per contact.
Panel Mount.
Solder Cup.
Gold.
Steel, Tin Plated.
UL94 V-0.
