| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
750 pcs
|
750 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Connector Type | |
| Contact Finish | |
| Current Rating | |
| Current Rating (Amps) | |
| Fastening Type | |
| Ingress Protection | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Feature | |
| Mounting Type | |
| Number of Positions | |
| Operating Temperature | |
| Orientation | |
| Primary Material | |
| Shell Material | |
| Shielding | |
| Storage Temperature | |
| Termination | |
| Termination Style | |
| Voltage Rating |
The 17281-3PG-300 is a 3-position male pin receptacle from Conxall/Switchcraft's Mini-Con-X series. It features a thermoplastic shell with a bayonet lock fastening system and a keyed orientation for secure mating. The connector is rated for 7.5A current and 600VAC/DC voltage, making it suitable for power and signal applications in harsh environments.
This panel mount receptacle uses solder termination and includes a bulkhead front side nut mounting feature. The contacts are gold plated for reliable conductivity. The connector is unshielded and has an IP67 ingress protection rating, ensuring dust tight and waterproof performance.
The operating temperature range is -40°C to 85°C. The shell material is thermoplastic with a UL94 HB flammability rating.
The current rating is 7.5A.
The voltage rating is 600VAC/DC.
Panel mount with through hole solder termination and bulkhead front side nut.
It has 3 positions.
IP67 - dust tight and waterproof.
