1727528 Blade fuse holder for ATC/ATO fuses, rated 30A at 32V. Through hole mounting with PC pin termination for PCB assembly.
Mfr Part #:

1727528

Available from 1 distributors
Mfr Name: Phoenix Contact
Phoenix Contact
Blade fuse holder for ATC/ATO fuses, rated 30A at 32V. Through hole mounting with PC pin termination for PCB assembly.
✓ Total Stock: 49 pcs

1727528 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Partservice ✓
Non-Authorised Inventory information
49 pcs
On Request
49 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

1727528 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Current Rating
Current Rating (Amps)
For Use With
Fuse Size
Fuse Type
Fuseholder Type
Lead Spacing
Lead Style
Mounting Type
Number of Circuits
Orientation
Termination Style
Voltage
Voltage Rating
View Similar Products (0)

1727528 Description

Short technical summary and product information.

The Phoenix Contact 1727528 is a single-circuit blade fuse holder designed for 5mm wide automotive flat-type fuses. It accepts ATC/ATO blade fuses and is rated for up to 30A current and 32V voltage. The holder features a through hole mounting style with PC pin termination, ensuring reliable connection to the PCB. The vertical orientation allows for space-efficient placement. A snap-in foot provides secure pre-assembly on the board before soldering. The fuse holder is approved by CSA, UL Recognized, and GOST, making it suitable for various applications including automotive, industrial, and electronic circuit protection. The compact design accommodates standard ATC/ATO fuse sizes of 0.75" x 0.2" (19.1mm x 5.1mm). Packing unit is 1 piece.

1727528 Quick Information

Product Type: Fuse Holder
Series: SI-H-FKS 30
Canonical Name: Fuse Holder for ATC/ATO Blade Fuses, 30A, 32V, Through Hole, PC Pin
Subcategory: Blade Fuse Holder

1727528 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected
Lead Free: Yes

1727528 Features

  • Blade type fuse holder for ATC/ATO fuses.
  • Rated 30A at 32V DC.
  • Through hole mounting with PC pin termination.
  • Vertical orientation for compact PCB layout.
  • Snap-in foot for secure pre-assembly.

1727528 Applications

  • Used in automotive fuse blocks and panels.
  • Ideal for PCB mounted circuit protection.
  • Suitable for industrial control systems.
  • For use with 5mm wide blade fuses.

1727528 FAQs

6 frequently asked questions generated from this part’s specifications.
What is the current rating of the Phoenix Contact 1727528 fuse holder?

The current rating is 30 A.

What is the voltage rating of this fuse holder?

The voltage rating is 32 V.

What type of fuse does the 1727528 accept?

It accepts blade fuses, specifically ATC and ATO types.

What is the mounting style of this fuse holder?

It is through hole mount with PC pin termination.

What is the orientation of the fuse holder on the PCB?

The orientation is vertical.

What approvals does the Phoenix Contact 1727528 have?

It is approved by CSA, UL Recognized, and GOST.
