| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
72 pcs
|
72 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Style | |
| Connector Type | |
| Contact Resistance | |
| Contact Type | |
| Current Rating | |
| Features | |
| Flange Feature | |
| Insulation Resistance | |
| Mating Cycles | |
| Mating Force per Contact | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Operating Temperature Range | |
| SVHC Present | |
| Shell Material, Finish | |
| Shell Size, Connector Layout | |
| Storage Temperature | |
| Test Voltage | |
| Unmating Force per Contact |
The Molex 1727040031 is a D-Sub Combo connector housing designed for use with male contacts. This plug housing accommodates up to 3 positions, which can be configured for coax or power contacts. The housing features a single row layout with shell size 2 (DA, A) - 3W3, making it suitable for mixed-signal or power applications.
The shell is constructed from steel with a tin-plated finish, providing durability and reliable grounding. The housing includes grounding indents for enhanced EMI performance. It is designed for free hanging (in-line) mounting with an unthreaded flange feature.
Electrical specifications from the datasheet indicate a current rating of 5 A per contact, test voltage of 1000 V, contact resistance of 2.7 mOhm, and insulation resistance of 5000 MOhm. The operating temperature range is -55°C to +130°C. The housing is rated for 500 mating cycles with a mating force of 3.4 N per contact.
This connector housing is part of Molex's D-Sub family and is RoHS3 compliant (unverified). It is suitable for applications requiring a compact, reliable interconnect for power and signal in industrial, automotive, or telecommunications equipment.
3 positions (coax or power).
5 A per contact.
1000 V between contacts or shell and contact.
Free hanging (in-line) with unthreaded flange.
-55°C to +130°C.
2.7 mOhm per mated contact.
500 cycles.
