The Molex 1724470502 is a 2-circuit, 2-row vertical header from the Mini-Fit Jr. series, designed for board-to-cable/wire interconnects. It features a 4.20mm pitch and a shrouded 4-wall housing that provides robust mating alignment and protection. The through-hole termination ensures reliable solder connections on PCBs.
This header is rated for 600VAC/DC and operates across a temperature range of -40°C to +105°C. The green polyamide (PA66/Nylon 6/6) insulation meets UL94 V-0 flammability standards. Contacts are made of brass with a full tin plating of 100µin (2.54µm) thickness, offering good corrosion resistance and solderability.
Mechanical features include a locking ramp fastening system for secure retention when mated with Mini-Fit Jr. receptacles, and an integrated board lock and glow wire compliance for enhanced reliability in demanding environments. The contact length is 3.56mm (0.140").
Typical applications include power supply connections, automotive systems, and industrial equipment where a compact, high-current capable interface is required. The current rating is dependent on the wire gauge used and should be verified per application.
The header has 2 positions.
The pitch is 4.20mm (0.165").
The voltage rating is 600VAC/DC.
Through hole mounting.
-40°C to +105°C.
Insulation is green polyamide (PA66/Nylon 6/6) with UL94 V-0 rating.
It is marked RoHS3 Compliant, but the compliance status is unverified (low confidence).
