| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
29,742 pcs
|
29742 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Resistance | |
| Contact Shape | |
| Contact Type | |
| Current Rating | |
| Dielectric Withstanding Voltage | |
| Durability | |
| Fastening Type | |
| Features | |
| Halogen Free | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Insulation Resistance | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Tape & Reel | |
| Termination | |
| Voltage Rating |
The Molex 172316-1108 is a wire-to-board power header from the Ultra-Fit series, designed for high-current applications in a compact 3.50mm pitch. It offers 8 positions in 2 rows with a 4.60mm row spacing, configured as a right-angle through-hole mounted shrouded header with 4-wall shrouding and a latch holder fastening system. The header accepts male pin contacts made of copper alloy with a tin finish (60.0µin thickness).
The connector is rated for 14.0A continuous current per circuit and 600VAC/DC voltage, with a contact resistance of 7 milliohms maximum and insulation resistance of 1000 Megohms minimum. It withstands 1800VAC dielectric strength. The operating temperature range is -40°C to 105°C. Mechanical features include a mating force of 4.5N maximum, contact insertion force of 14.7N, and a durability of 25 cycles minimum.
The housing is molded from black liquid crystal polymer (LCP) rated UL94 V-0, with a board guide feature for alignment. The part is RoHS3 compliant, halogen-free, and glow wire capable. Packaging options include bag, tray, or reel. This header is suitable for use in consumer appliances, telecommunications, industrial equipment, and medical devices.
| Qty | Low | High |
|---|---|---|
| 1+ | $8.38 | $8.38 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The connector has 8 positions.
The pitch is 3.50mm (0.138").
The maximum current rating is 14.0A per circuit.
The voltage rating is 600VAC/DC.
Through hole, right angle mounting.
The operating temperature range is -40°C to 105°C.
Yes, it is RoHS3 compliant verified by the datasheet.
