The E-T-A 1658-G41-00-P10-30A is a single-pole, thermal overcurrent circuit breaker designed for cost-effective protection in various applications. It offers a current rating range of 5 to 30 Amps and a voltage rating of up to 240 VAC or 28 VDC.
Key electrical specifications include an interrupting capacity of 2000A at specified voltage and current levels, and a dielectric strength of 3000V AC. The breaker operates within an ambient temperature range of -20°C to +60°C, with a reduced maximum temperature of +40°C for currents below 8A.
Designed for reliability, it meets international requirements and features a manual reset actuator with a cycling trip-free mechanism. The device is built to withstand environmental stresses, including vibration up to 8g and shock up to 30g, and has undergone corrosion and humidity testing.
This circuit breaker is suitable for panel mounting and is approved by VDE, UL, and CSA. Typical applications include battery chargers, consumer products, power supplies, and motors.
The circuit breaker is rated for 240 VAC and 28 VDC.
The current rating is 30 A.
The operating temperature range is -20°C to +60°C, with a maximum of +40°C for currents below 8A.
It uses a manual reset (push-to-reset) actuator.
The interrupting capacity (Icn) is 200 A, and under specific conditions (e.g., 5-16A at 240VAC) it is 2000 A.
It has VDE (EN 60934) approval for AC 240V/DC 28V up to 25A, and UL/CSA approval for various AC and DC ratings up to 30A.
The operating area has an IP40 degree of protection.
