This E-T-A 1658-G41-00-P10-055838-14A is a thermal overcurrent circuit breaker designed for reliable circuit protection. It features a single pole configuration and a manual push-to-reset actuator for easy operation.
The breaker is rated for 14A current and can handle up to 240V AC or 28V DC. It is built with a cycling trip-free mechanism and has no exposed metal parts, enhancing safety. The device meets international requirements and is approved by UL, CSA, VDE, and EN 60934 (IEC 60934).
With a panel mount design, this circuit breaker is suitable for various applications including battery chargers, consumer products, power supplies, and motors. Its compact and lightweight construction makes it a versatile component for integration into different systems. The operating temperature range is -20°C to +60°C.
240V AC and 28V DC.
-20 to +60°C, with a maximum of +40°C for currents ≤7A.
200A at 240VAC, 2000A at 240VAC (for 5-16A), 2500A at 32VDC, 2000A at 28VDC.
Push-to-reset.
1 pole.
Panel mount.
Battery chargers, consumer products, power supplies, motors.
