The E-T-A 1658-F01-00-P13-5A is a thermal overcurrent circuit breaker designed for cost-effective protection in various applications. It features a manual reset mechanism and a cycling trip-free design.
This single-pole breaker has a current rating of 5A and can handle up to 240VAC or 28VDC. It is approved to international standards including UL, CSA, VDE, and EN 60934 (IEC 60934).
The breaker is designed with no exposed metal parts that could become current-carrying, except for the terminals. It offers a panel mount configuration and utilizes blade terminals for connection. Typical applications include battery chargers, consumer products, power supplies, and motors.
Key technical data includes an interrupting capacity of 180A to 200A depending on the current rating, and a typical operating life of 1,000 operations at 2x In. The operating temperature range is -20°C to +60°C.
The circuit breaker is rated for 240VAC and 28VDC.
It is a panel mount circuit breaker with blade terminals.
The ambient temperature range is -20°C to +60°C, derated to +40°C for ratings ≤7A.
Interrupting capacity varies: 180A (5-7A), 200A (8-30A) per Icn; 2000-2500A per UL 1077/EN 60934 depending on voltage and current range.
Typical life is 1000 operations at 2x rated current (inductive for 5-16A, resistive for 17-25A).
Vibration: 8g (57-500 Hz) with 0.61mm displacement (10-57 Hz). Shock: 30g for 11ms.
