| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Illumination | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Voltage Rating |
This E-T-A 1658-F01-00-P10-D01-18A is a thermal overcurrent circuit breaker with a manual reset mechanism. It is designed for panel mounting and operates at a voltage rating of 240VAC or 28VDC, with a current rating of 18A.
Key electrical specifications include an interrupting capacity of up to 200A (Icn) and 2500A (UL/EN). The breaker operates within an ambient temperature range of -20°C to +60°C. It meets international requirements with no exposed current-carrying metal parts except for terminals.
Typical applications for this cost-effective design include battery chargers, consumer products, power supplies, and motors. The unit is approved to UL, CSA, VDE, and EN 60934 (IEC 60934) standards. It features blade terminals for connection.
240VAC and 28VDC.
-20 to +60°C, with a maximum of +40°C for currents ≤7A.
Panel mount with blade terminals A6.3-0.8 (QC .250).
Varies by current and voltage: up to 2000A AC at 240V, up to 2500A DC at 32V.
1000 operations at 2x rated current for inductive and resistive loads.
Push-to-reset.
1 pole.
