| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
297 pcs
|
297 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Style | |
| Connector Type | |
| Contact Type | |
| Features | |
| Flange Feature | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Shell Finish Thickness | |
| Shell Material, Finish | |
| Shell Size, Connector Layout | |
| Tape & Reel |
The Conec 163X10019X is a D-Sub connector housing designed for use with male contacts. It provides a 9-position, 2-row configuration in a plug (male) orientation. The housing is intended for free hanging (in-line) mounting, making it suitable for cable-to-cable or cable-to-panel applications where a panel cutout is not required.
The shell is constructed from steel with a tin-plated finish, offering durability and good conductivity for grounding purposes. The shell finish thickness is 315 microinches (8.00 micrometers). This housing includes grounding indents to help ensure a reliable ground connection between the connector and the mating shell.
The connector layout is shell size 1 (DE, E), which is the standard size for 9-position D-Sub connectors. The flange feature is housing/shell (unthreaded), meaning it does not include threaded inserts for jackscrews.
The Conec 163X10019X D-Sub housing has 9 positions arranged in 2 rows.
The mounting style is free hanging (in-line), meaning it is designed for cable mounting without requiring a panel cutout.
The shell is made of steel with a tin-plated finish. The finish thickness is 315 microinches (8.00 micrometers).
Yes, the housing includes grounding indents to facilitate a reliable ground connection.
The shell size is 1 (DE, E), which is the standard size for 9-position D-Sub connectors.
