| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
60 pcs
|
60 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Cable Diameter Range | |
| Connector Type | |
| Contact Size | |
| Contact Type | |
| Fastening Type | |
| Features | |
| Housing Color | |
| Ingress Protection | |
| Lead Style | |
| Mounting Type | |
| Nominal Current (Power Contact) | |
| Nominal Voltage (Power Contact) | |
| Number of Positions | |
| Operating Temperature Range | |
| Orientation | |
| Overvoltage Category | |
| Pollution Degree | |
| Rated Surge Voltage | |
| SVHC Present | |
| Shell Material | |
| Shell Size | |
| Shielding | |
| Standard Package Quantity | |
| Storage Temperature | |
| Termination Style | |
| Type |
The Phoenix Contact 1624550 is a circular cable connector plug housing from the ST-6ES1N8A8005S series. It features a metal shell with M17-7 sizing and silver finish. The housing accommodates up to 7 crimp contacts (6 power plus PE) with 1mm contact diameter. It is designed for free hanging (in-line) mounting and supports cable diameters from 10 mm to 12.5 mm. The SPEEDCON push-twist locking mechanism enables quick and secure mating without tools. The product is fully shielded for EMC protection and rated IP67 for dust tight and waterproof operation in harsh environments. Operating temperature range is -40°C to 125°C. Key electrical ratings for power contacts include 14 A nominal current at 25°C, 630 V nominal voltage, 6 kV rated surge voltage, overvoltage category III, and pollution degree 3. A backshell and coupling nut are included. Crimp contacts must be ordered separately.
IP67 — dust tight and waterproof.
7 positions: 6 power plus PE (protective earth).
Push-twist SPEEDCON locking.
-40°C to 125°C.
14 A at 25°C.
Cable diameter range 10 mm to 12.5 mm.
Free hanging (in-line) mounting.
