| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Cord Length | |
| Current | |
| Efficiency | |
| Form | |
| Input Connector | |
| Input Type | |
| Medical Grade | |
| Operating Temperature | |
| Output Connector | |
| Polarization | |
| Power (Watts) | |
| Region Utilized | |
| Standard Number | |
| Voltage |
This AC/DC external wall mount adapter from Ideal Power Ltd., model 15DYS851-240210G-K, delivers 50 watts of power with a stable 24V output and a maximum current of 2.1A. Designed for efficiency, it meets Level VI standards, ensuring reduced energy consumption.
The adapter features a universal input voltage range of 90-264 VAC and utilizes a convenient multi-blade input connector. The output is delivered via a standard barrel plug (2.1mm I.D. x 5.5mm O.D. x 11.0mm) with positive center polarization. Its compact dimensions of 84.0mm x 53.0mm x 38.0mm make it suitable for various applications.
With an operating temperature range of 0°C to 40°C, this adapter is suitable for demanding environments. It is certified by multiple agencies including CE, C-Tick, cULus, FCC, TUV, and UKCA, ensuring compliance with international safety and performance standards. The adapter is specifically noted for its suitability in medical applications, adhering to the IEC 60601-1 standard.
The 15DYS851-240210G-K provides a 24V output voltage and a maximum output current of 2.1A.
The adapter has a power rating of 50W.
The input voltage range is 90 to 264 VAC.
This adapter meets Level VI efficiency standards.
The operating temperature range is from 0°C to 40°C.
It uses a Barrel Plug with dimensions 2.1mm I.D. x 5.5mm O.D. x 11.0mm.
The dimensions are 84.0mm in length, 53.0mm in width, and 38.0mm in height.
