| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
33,000 pcs
|
33000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
10 pcs
|
10 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Actuator Level | |
| Actuator Type | |
| Circuit | |
| Contact Finish | |
| Contact Material | |
| Current Rating (Amps) | |
| Height Above Board | |
| Mounting Type | |
| Number of Positions | |
| Operating Temperature | |
| Pitch | |
| Tape & Reel | |
| Termination Style | |
| Voltage Rating | |
| Washable |
The TE Connectivity 1571999-4 is a SPST (Single Pole Single Throw) DIP switch designed for surface mount applications with a right-angle orientation. It features a piano-style actuator and gull wing termination style with a gold contact finish over a copper alloy contact material.
This switch is rated for a voltage of 24VDC and a current of 25mA. The operating temperature range is from -30°C to 85°C. The pitch is 2.54mm (0.100"), and the height above the board is 6.93mm (0.273"). The switch is washable and has a Moisture Sensitivity Level (MSL) of 1.
It is suitable for various electronic applications requiring manual switching in a compact form factor. The surface mount, right-angle design allows for efficient PCB space utilization.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.75 | $0.75 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
-30°C to 85°C
Surface Mount, Right Angle
SPST
Gold
Yes
