| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1 pcs
|
1 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Container Type | |
| Design | |
| Height | |
| Inside Box Length | |
| Inside Box Width | |
| Inside Height | |
| Length | |
| Material | |
| Packaging Type | |
| Ratings | |
| Recommended Torque | |
| Screw Size | |
| Shipping Weight | |
| Thickness | |
| Width |
The Hammond Manufacturing 1550GBK is a black diecast aluminum enclosure from the 1550 series. It features a box design with a cover included, secured by six M3.5-0.6 x 12mm screws with a recommended torque of 75 ozf.in / 55 cN.m. The enclosure is rated IP54 for dust and water resistance.
External dimensions are 222.00mm (8.740") length, 146.00mm (5.748") width, and 55.09mm (2.169") height. Internal usable space measures 215.46mm length, 127.46mm width, and 51.10mm height. The wall thickness is 2.01mm (0.079").
The enclosure is made from diecast aluminum alloy with a black textured finish. It is shipped in shrink wrap packaging with a shipping weight of 0.60 kg (1.32 lbs). The part is RoHS3 compliant and REACH unaffected. Replacement gasket kits (1550GEGASKET for IP66, 1550GSGASKET for IP67) and screw packs (1550MS100BK) are available separately.
Yes, the 1550GBK is RoHS3 compliant as verified on the manufacturer page.
The enclosure is rated IP54 for dust and water resistance.
The enclosure is made of diecast aluminum alloy.
External dimensions are 222.00mm (8.740") length, 146.00mm (5.748") width, and 55.09mm (2.169") height.
Internal dimensions are 215.46mm length, 127.46mm width, and 51.10mm height.
The enclosure uses M3.5-0.6 x 12mm cover screws with a recommended torque of 75 ozf.in / 55 cN.m.
The shipping weight is 0.60 kg (1.32 lbs).
