| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2,004 pcs
|
2004 pcs | On Request | 1 | On Request | On Request | 24+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Connector Type | |
| Contact Carrier Material | |
| Contact Finish | |
| Contact Material | |
| Contact Resistance | |
| Current Rating (Amps) | |
| Fastening Type | |
| Features | |
| Industrial Grade | |
| Ingress Protection | |
| Insulation Resistance | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Feature | |
| Mounting Type | |
| Number of Positions | |
| Operating Temperature | |
| Orientation | |
| Pollution Degree | |
| Primary Material | |
| Sealing Material | |
| Shell Finish | |
| Shell Material | |
| Shell Size | |
| Shielding | |
| Standard Package Quantity | |
| Status Display | |
| Surge Voltage Category | |
| Termination | |
| Termination Style | |
| Voltage Rating | |
| Weight |
The Phoenix Contact 1534630 (SACC-DSIV-M12FSD-4CON-L90) is an M12-4 circular connector receptacle with 4 female socket contacts. It features a D-coded orientation, threaded fastening, and is fully shielded for reliable signal integrity in industrial Ethernet applications. The connector is rated for 4 A at 250 V and offers an IP67 ingress protection rating, making it suitable for harsh environments.
The shell is constructed from nickel-plated zinc die cast with a silver finish, while the contacts are gold-plated on a copper zinc alloy (CuZn) base. The contact carrier is made of PA 66 and the seal is NBR. This receptacle is designed for panel mount, through-hole, right-angle installation with a bulkhead (rear side nut) mounting feature. Solder termination is used with solder pins.
Electrical performance includes a contact resistance of ≤ 3 mΩ and insulation resistance ≥ 100 MΩ. The operating temperature range from the datasheet is -25°C to 85°C (note a conflicting range of -40°C to 85°C in existing database). The part is RoHS3 compliant per the datasheet, which notes WEEE/RoHS compliance since March 2006. Pollution degree 3 and surge voltage category II are specified.
Standard packaging quantity is 10 pieces per pack. The part number 1534630 is also known as the manufacturer model number SACC-DSIV-M12FSD-4CON-L90 and has an EAN barcode 4046356026802.
| Qty | Low | High |
|---|---|---|
| 1+ | $28.51 | $28.51 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
It has 4 positions (female sockets).
The nominal current rating is 4 A.
The nominal voltage rating is 250 V.
It is panel mount, through hole, right angle with a bulkhead-rear side nut mounting feature.
Yes, it is shielded.
The ingress protection rating is IP67 (dust tight and waterproof).
Per the datasheet, the operating temperature range is -25°C to 85°C. Note: existing database lists -40°C to 85°C, a conflict exists.
