| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1 pcs
|
1 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Connector Type | |
| Contact Finish | |
| Current Rating (Amps) | |
| Fastening Type | |
| Features | |
| Ingress Protection | |
| Material Flammability Rating | |
| Mounting Feature | |
| Mounting Type | |
| Number of Positions | |
| Operating Temperature | |
| Orientation | |
| Primary Material | |
| Shell Finish | |
| Shell Material | |
| Shell Size | |
| Shielding | |
| Termination | |
| Termination Style | |
| Voltage Rating |
The Phoenix Contact 1436550 is a M12-4 circular connector receptacle designed for reliable connections in harsh environments. It features 4 female sockets with gold-plated contacts for corrosion resistance and reliable signal transmission. The connector is rated for 4A at 250V and has an IP67 ingress protection rating, making it suitable for dust-tight and waterproof applications. The receptacle is panel mounted with a rear side nut bulkhead feature and uses a right-angle solder termination. The shell is made of zinc die-cast with a nickel finish, providing durability and shielding. The connector includes board guide and board lock features for secure PCB mounting. Operating temperature range is -25°C to 85°C. The material flammability rating is UL94 V-0. The connector uses a push-twist fastening type and is orientation D coded.
4 positions.
4 A.
250 V.
Panel mount, through hole, right angle.
IP67 - Dust Tight, Waterproof.
-25°C to 85°C.
Zinc die cast with nickel finish.
