| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
5 pcs
|
5 pcs | On Request | 1 | On Request | On Request | 2026-02-25 06:16:38 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Connector Type | |
| Contact Mating Finish | |
| Current | |
| Current Rating | |
| Features | |
| Lead Spacing | |
| Mounting Type | |
| Number of Levels | |
| Number of Positions | |
| Operating Temperature | |
| Pitch | |
| Plug Wire Entry | |
| Positions Per Level | |
| SVHC Present | |
| Termination Style | |
| Type | |
| Voltage | |
| Voltage Rating | |
| Wire Gauge | |
| Wire Gauge or Range |
The Harting 14310713101000 is a 7-position terminal block plug designed for use in industrial control and automation systems. It features a single level with 7 positions per level at a 2.54mm pitch, utilizing a screwless spring cage (tension clamp) termination for quick and reliable wire installation without tools. The plug accepts wire sizes from 0.14 to 0.5mm² and is rated for 6A at 160V. It supports free hanging (in-line) mounting with a 180° plug wire entry, and includes a latch lock for secure mating with corresponding headers. The housing is black, with tin-plated contacts and an operating temperature range of -40°C to 125°C, making it suitable for demanding environments. This plug is ideal for use in terminal block systems requiring a compact, high-density interconnect solution.
7 positions.
2.54mm (0.100").
6 A.
160 V.
Free hanging (in-line).
Screwless - spring cage, tension clamp.
