| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
10 pcs
|
10 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Cable Length | |
| Color | |
| Connector Type | |
| Contact Finish | |
| Current Rating | |
| Current Rating (Amps) | |
| Fastening Type | |
| Halogen Free | |
| Ingress Protection | |
| Material Flammability Rating | |
| Mounting Feature | |
| Mounting Type | |
| Number of Positions | |
| Primary Material | |
| SVHC Present | |
| Shell Material | |
| Shielding | |
| Termination | |
| Termination Style | |
| Voltage Rating |
The Phoenix Contact 1409213 is a circular connector plug designed for reliable power and signal connections in demanding environments. It features 5 male pin contacts, a panel mount with bulkhead front side nut, and a snap-in latch lock fastening mechanism. The termination type is wire leads, with a cable length of approximately 0.49 feet.
This connector is rated for 30A current and 600VAC voltage, making it suitable for medium-power applications. The shell is made of polyphenylene ether (PPE) plastic with a UL94 V-0 flammability rating, ensuring safety in high-temperature conditions. The contact finish is silver, providing good conductivity and corrosion resistance.
The connector offers a high degree of ingress protection with IP65, IP66, IP68, and IP69K ratings, indicating it is dust-tight and resistant to water jets, immersion, and high-pressure steam cleaning. This makes it ideal for outdoor, industrial, and harsh environment applications. The unshielded design is suitable for general-purpose use where electromagnetic interference is not a concern.
This connector has 5 positions.
The current rating is 30A.
The voltage rating is 600VAC.
The mounting type is panel mount with a bulkhead front side nut.
The ingress protection rating is IP65, IP66, IP68, and IP69K, meaning it is dust tight, water resistant, and waterproof.
The shell material is polyphenylene ether (PPE) plastic.
The material flammability rating is UL94 V-0.
