| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
22 pcs
|
22 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Current | |
| Current Rating | |
| Features | |
| Lead Spacing | |
| Mating Orientation | |
| Mounting Type | |
| Number of Levels | |
| Pitch | |
| Positions Per Level | |
| SVHC Present | |
| Tape & Reel | |
| Termination Style | |
| Voltage | |
| Voltage Rating | |
| Wire Gauge | |
| Wire Termination |
The Harting 14010413101000 is a compact 4-position wire to board terminal block with a 2.54mm pitch, designed for space-constrained PCB applications. It features a screwless spring cage (tension clamp) termination mechanism for quick and reliable wire connections without the need for tools. The part is rated for 6 A current and 160 V voltage, with an acceptable wire range of 20-26 AWG. The vertical mating orientation with the board simplifies routing in low-profile designs.
The terminal block is surface mount compatible and includes integrated features such as a board guide for accurate placement and solder retention for reliable soldering during reflow processes. The black housing is suitable for visual contrast on standard PCB finishes. The 2.54mm pitch allows for high-density wiring in control, sensor, and signal applications. This component is designed to meet RoHS and REACH environmental standards, though these certifications are unverified. No operating temperature range or housing material data is available from the provided sources.
This terminal block has 4 positions (single level).
The pitch is 2.54mm (0.100 inches).
It is rated for 6 A and 160 V.
It uses a screwless spring cage (tension clamp) termination.
The mounting type is surface mount (SMD).
