14.31818MHZ This 14.31818MHz crystal oscillator from SUNNY is designed for SMT applications. It operates at 3.3V and has a wide operating temperature range.
Mfr Part #:

14.31818MHZ

Available from 1 distributors
Mfr Name: Sunny
Sunny
This 14.31818MHz crystal oscillator from SUNNY is designed for SMT applications. It operates at 3.3V and has a wide operating temperature range.
✓ Total Stock: 100 pcs
$ Price Range: $0.50

14.31818MHZ Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Spartce Electronics. ✓
Non-Authorised Inventory information
100 pcs
On Request
100 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

14.31818MHZ Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Frequency
Mounting Type
Operating Temperature
SVHC Present
Supply Voltage
View Similar Products (0)

14.31818MHZ Description

Short technical summary and product information.

The SUNNY 14.31818MHZ is a crystal oscillator suitable for various electronic applications. It features a compact 5.0 x 3.2 x 1.3mm SMT package, making it ideal for high-density circuit boards.



This oscillator operates with a nominal supply voltage of 3.3V and offers a frequency stability of ±100 ppm over an operating temperature range of -10°C to +70°C. Key electrical specifications include a typical output load of 15 pF, symmetry between 40% and 60%, and a rise/fall time of 5-10 ns for frequencies up to 29.9MHz.



It also includes a tri-state function for output control and a disable current of 10 µA. The start-up time is typically between 1 to 10 ms. This component is designed for reliable performance in demanding environments.

14.31818MHZ Quick Information

Product Type: Crystal
Canonical Name: 14.31818MHz Crystal Oscillator
Subcategory: Crystal

14.31818MHZ Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected
Lead Free: Yes

14.31818MHZ Estimated Pricing

Qty Low High
1+ $0.50 $0.50

Estimated market price range - modelled values for guidance only, not live distributor offers.

14.31818MHZ Features

  • 14.31818MHz nominal frequency output.
  • 3.3V HCMOS/TTL compatible supply voltage.
  • Wide -10 to +70°C operating temperature.
  • Compact 5.0 x 3.2 x 1.3mm SMT package.
  • Tri-state function for output control.

14.31818MHZ Applications

  • Suitable for high-density SMT.
  • Used in PC or PC card equipment.
  • Ideal for thin equipment designs.
  • Applicable for wireless communication.

14.31818MHZ FAQs

7 frequently asked questions generated from this part’s specifications.
What is the supply voltage for this oscillator?

3.3 V.

What is the package size of this crystal oscillator?

5.0 x 3.2 x 1.3mm.

What is the operating temperature range?

-10 to +70 °C.

What is the nominal frequency of this oscillator?

14.31818 MHz.

What is the frequency stability of this oscillator?

±100 ppm.

What is the output symmetry (duty cycle) of this oscillator?

40 to 60% at 1/2 Vdd.

Does this oscillator have a tri-state function?

Yes, it has a tri-state function that disables the output (Hi-Z) when the enable pin is low.
