| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
520 pcs
|
520 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Features | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Shrouding | |
| Style | |
| Termination | |
| Termination Style | |
| Voltage Rating |
The 1376136-2 is a 6-position, 2-row, right angle header from TE Connectivity with a 2.5mm pitch. It is a shrouded (4-wall) design with a detent lock for secure mating. The header can be used for board-to-board or cable connections. Contacts are made of copper alloy with a tin finish (15.0µin / 0.38µm). The insulation is black thermoplastic, polyester, glass filled with a UL94 V-0 flammability rating. The insulation height is 14.70mm (0.579") and the contact length is 3.40mm (0.134"). This header is rated for 5A at 250VAC and operates over -55°C to 105°C. It includes a board lock feature for additional retention. Termination is through hole, right angle with solder.
| Qty | Low | High |
|---|---|---|
| 1+ | $4.53 | $4.53 |
| 46+ | $3.46 | $3.46 |
| 138+ | $3.20 | $3.20 |
| 506+ | $2.92 | $2.92 |
| 1,012+ | $2.78 | $2.78 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
6 positions, all loaded, in 2 rows.
2.50mm (0.098 inches).
5A.
250VAC.
Through hole, right angle with solder termination.
-55°C to 105°C.
Tin, 15.0µin (0.38µm) thickness.
