| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
23 pcs
|
23 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Actuator Height off PCB, Vertical | |
| Actuator Orientation | |
| Actuator Type | |
| Circuit | |
| Contact Material | |
| Contact Rating @ Voltage | |
| Features | |
| Illumination | |
| Ingress Protection | |
| Mounting Type | |
| Operating Force | |
| Operating Temperature | |
| Outline | |
| Storage Temperature | |
| Switch Function | |
| Tape & Reel | |
| Termination Style |
The Schurter Inc. 1241.1022 is a tactile switch designed for reliable input feedback. It features a Single Pole Single Throw Normally Open (SPST-NO) circuit and an Off-Mom (momentary) switch function.
This switch has a contact rating of 0.05A at 24VDC and a rated switching capacity of 0.48W. It is built with gold contacts, offering a contact resistance of less than 50 mΩ, even after a million actuations. The actuating force is typically 250gf with an actuating travel of 0.45mm.
Designed for Through Hole mounting, the 1241.1022 has a vertical actuator height of 7.75mm and a termination style of PC Pin. Its outline dimensions are 12.65mm x 12.65mm. The operating temperature range is -25°C to 85°C, and it provides an IP40 ingress protection rating.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.75 | $0.75 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The Schurter Inc. 1241.1022 tactile switch has a maximum switching voltage of 24 VDC.
The contact rating is 0.05A at 24VDC.
The operating temperature range is -25°C to 85°C.
The ingress protection rating is IP40.
This tactile switch is designed for Through Hole mounting.
The circuit configuration is SPST-NO (Single Pole Single Throw Normally Open).
The lifetime is expected to be over 1 million actuations at the rated switching capacity.
