| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1 pcs
|
1 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Mounting Type | |
| Number of Positions | |
| Pitch | |
| Rated Current | |
| Rated Voltage | |
| Temperature Range | |
| Torque |
The WECO Electrical Connectors Inc. 121-A-111/15 is a plug connector with a pitch of 5.08 mm, designed for reliable wire-to-board connections. This specific model offers 15 positions, accommodating multiple connections within a compact footprint.
Technical specifications include a rated current of 12 A and a rated voltage of up to 630 V, with an Over Voltage Category III rating. The clamping range for wires is from 0.2 to 4 mm² for solid conductors and 0.2 to 2.5 mm² for flexible conductors, supporting AWG 26-12. The wire stripping length is specified as 7 mm ± 0.5 mm, and a torque of 0.5 Nm is recommended for secure connections.
The connector is constructed with a PA, grey, V-0 moulding material, ensuring flame retardancy. Terminal components are made from nickel-plated brass, with tin-plated tin bronze springs and pressure clamps, and M3 zinc-plated steel screws. It operates within a temperature range of -40°C to 100°C and has a Comparative Tracking Index (CTI) of ≥ 600, placing it in Insulating Group I.
Options such as consecutive numbering, special marking, self-adhesive marking strips, coding elements, and strain relief are available to customize the connector for specific application needs. This series is usable with all pin strips of series 121.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.00 | $1.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The pitch of the WECO 121-A-111/15 connector is 5.08 mm.
The 121-A-111/15 connector has 15 positions.
The rated current for the 121-A-111/15 connector is 12 A.
The maximum rated voltage for the 121-A-111/15 connector is 630 V.
The operating temperature range for this connector is -40°C to 100°C.
The terminal body is nickel-plated brass, and the screw is M3 zinc-plated steel, blue passivated.
