| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
20 pcs
|
20 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Actuator Length | |
| Actuator Material | |
| Actuator Type | |
| Circuit | |
| Contact Finish | |
| Contact Material | |
| Contact Resistance | |
| Contact Timing | |
| Current Rating (Amps) | |
| Features | |
| Housing Material | |
| Insulation Resistance | |
| Mounting Type | |
| Operating Temperature | |
| Switch Function | |
| Termination Style | |
| Voltage Rating |
The C&K Components 1201M2S3AQE2 is a miniature slide switch from the 1000 Series. This DPDT (Double Pole, Double Throw) switch features a standard actuator and PC pin termination style, suitable for through-hole, right-angle mounting.
It is rated for 6 Amps at 120 Volts AC/DC and has a contact resistance below 10 mΩ typical. The electrical life is rated for 40,000 cycles. The switch operates within a temperature range of -30°C to 65°C.
Materials include a Diallyl phthalate (DAP) case, Nylon actuator, and stainless steel housing. The end contacts are copper alloy with gold plating, and center contacts/terminals are also copper alloy with silver plating. The terminals are epoxy sealed, making them compatible with bottom-wash cleaning processes.
This switch is commonly found in applications such as test & measurement equipment, telecommunications, and computers & peripherals.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.75 | $0.75 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The Q contact material is rated for 6 amps at 120 V AC or 28 V DC.
The operating temperature range is -30°C to 65°C.
It supports through-hole, right-angle mounting.
Yes, it is RoHS3 Compliant.
